Mini PC RAM Upgrade: Your Complete Step-by-Step Guide
Thinking about a mini PC RAM upgrade? Boosting speed and multitasking power is easier than you imagine. This guide walks you through choosing the right memory and installing it correctly, step by step. 🚀 Get ready for a faster, more responsive compact PC experience!
|
Loading tags...
Is your compact powerhouse feeling a bit… cramped? When multitasking makes your mini PC stutter, it’s not time for a replacement—it’s time for a boost. A simple mini PC RAM upgrade is one of the quickest, most affordable ways to inject new life into your machine. It’s a 15-minute job that can transform your daily workflow and gaming sessions. Let’s get you sorted. ✨
MSI Cubi NUC AI+ 2MG-026ZA Mini Desktop / Intel Core Ultra 9 288V (8x Cores, 8x Threads, 3.30GHz Base) up to 5.10GHz / LPDDR5x 32GB RAM / 1TB NVMe SSD / Integrated Intel Arc Graphics / Windows 11 Pro / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A, 2x Thunderbolt 4, 1x Microphone & Headphone Combo Jack, 1x Micro-SD Card Reader, 1x Power Button with Fingerprint Security Design, 1x Copilot Button, 2x RJ45, 1x HDMI, 1x Kensington Lock, 1x External Power Switch Pin Header / 9S6-B20611-026
R23499.00In Stock
MSI Cubi NUC AI 1UMG Mini PC Intel Core Ultra 5(up to 4.5GHz) Desktop Computer, DDR5 16GB RAM 512GB SSD, 2x HDMI, 2x USB Type-A, 2x USB Type-C (Thunderbolt 4 / DisplayPort 1.4) , 1x 2.5G LAN Port / 9S6-B20911-059
R15199.00In Stock
MINISFORUM Mini PC NAB6 Lite Intel Core i5-12600H,12 Cores 16 Threads,up to 4.5GHz 32GB RAM DDR4 1TB PCIe4.0 SSD Dual 2.5 G RJ45 LAN Mini Desktop Computer,2 x HDMI,7 x USB Port,WiFi 6,BT5.2 / NAB6-Lite
R8999.00In Stock
MSI Cubi NUC AI+ 2MG-041ZA Mini PC / Intel Core Ultra 5 226V (8x Cores, 8x Threads, 2.1GHz Base) up to 4.5GHz / 16GB LPDDR5x RAM / 512GB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Professional / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports Thunderbolt 4, DisplayPort) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-041
R17499.00In Stock
MSI Cubi NUC AI+ 2MG-027ZA Mini PC / Intel Core Ultra 7 258V (8x Cores, 8x Threads, 2.2GHz Base) up to 4.8GHz / 32GB LPDDR5x RAM / 1TB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Home / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports ) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-027
R19999.00In Stock
MINISFORUM AI X1-255 Mini PC with AMD Ryzen 7 255 (8C/16T, up to 5.1 GHz), 16GB DDR5 Memory, 512GB SSD Storage, HDMI/DP/USB4 (4K@120 Hz), Dual Speaker/DMIC,USB-A X 3, 2.5G LAN, Wi-Fi 7/BT5.4 / AI-X1-255
R9999.00In Stock
Why a Mini PC RAM Upgrade is Worth It
Think of RAM (Random Access Memory) as your computer's short-term workspace. The more you have, the more applications and browser tabs you can run simultaneously without things grinding to a halt. For a mini PC, which often handles everything from home office duties to 4K media streaming, this is crucial.
A quick RAM upgrade delivers:
- Snappier Multitasking: Switch between Discord, Chrome, and your game without frustrating delays.
- Smoother Performance: Demanding applications like Photoshop or video editors will feel more responsive.
- Better Integrated Graphics Performance: iGPUs use system RAM as video memory (VRAM), so more (and faster) RAM can give you a welcome FPS boost in casual games.
It's one of the most cost-effective performance boosts you can give to any of our range of powerful mini PCs, extending its useful life for years.
Before You Begin: Choosing the Right RAM
Grabbing any old memory stick won't work. Compatibility is key to a successful mini PC RAM upgrade. Here’s what you need to check before you buy.
Check Compatibility First
Mini PCs almost exclusively use SODIMM (Small Outline Dual In-line Memory Module) sticks, which are shorter than the standard DIMMs used in desktop towers.
You also need to match the RAM generation. Is your machine using DDR4 or the newer DDR5? They are not cross-compatible. Your mini PC’s product page on Evetech or the manufacturer's official manual is the best place to find this info, along with the maximum amount and speed of RAM it supports.
MINISFORUM AI X1-255 Mini PC with AMD Ryzen 7 255 (8C/16T, up to 5.1 GHz), 16GB DDR5 Memory, 512GB SSD Storage, HDMI/DP/USB4 (4K@120 Hz), Dual Speaker/DMIC,USB-A X 3, 2.5G LAN, Wi-Fi 7/BT5.4 / AI-X1-255
R9999.00In Stock
MSI Cubi NUC AI+ 2MG-026ZA Mini Desktop / Intel Core Ultra 9 288V (8x Cores, 8x Threads, 3.30GHz Base) up to 5.10GHz / LPDDR5x 32GB RAM / 1TB NVMe SSD / Integrated Intel Arc Graphics / Windows 11 Pro / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A, 2x Thunderbolt 4, 1x Microphone & Headphone Combo Jack, 1x Micro-SD Card Reader, 1x Power Button with Fingerprint Security Design, 1x Copilot Button, 2x RJ45, 1x HDMI, 1x Kensington Lock, 1x External Power Switch Pin Header / 9S6-B20611-026
R23499.00In Stock
MSI Cubi NUC AI+ 2MG-041ZA Mini PC / Intel Core Ultra 5 226V (8x Cores, 8x Threads, 2.1GHz Base) up to 4.5GHz / 16GB LPDDR5x RAM / 512GB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Professional / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports Thunderbolt 4, DisplayPort) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-041
R17499.00In Stock
MSI Cubi NUC AI 1UMG Mini PC Intel Core Ultra 5(up to 4.5GHz) Desktop Computer, DDR5 16GB RAM 512GB SSD, 2x HDMI, 2x USB Type-A, 2x USB Type-C (Thunderbolt 4 / DisplayPort 1.4) , 1x 2.5G LAN Port / 9S6-B20911-059
R15199.00In Stock
MSI Cubi NUC AI+ 2MG-027ZA Mini PC / Intel Core Ultra 7 258V (8x Cores, 8x Threads, 2.2GHz Base) up to 4.8GHz / 32GB LPDDR5x RAM / 1TB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Home / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports ) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-027
R19999.00In Stock
MINISFORUM Mini PC NAB6 Lite Intel Core i5-12600H,12 Cores 16 Threads,up to 4.5GHz 32GB RAM DDR4 1TB PCIe4.0 SSD Dual 2.5 G RJ45 LAN Mini Desktop Computer,2 x HDMI,7 x USB Port,WiFi 6,BT5.2 / NAB6-Lite
R8999.00In Stock
How Much RAM Do You Need?
- 8GB: The absolute minimum for basic browsing and office work. If you're here, you likely need an upgrade.
- 16GB: The sweet spot for most South African gamers and power users. It provides enough headroom for modern games, heavy multitasking, and creative work.
- 32GB+: Ideal for professionals doing heavy video editing, running virtual machines, or anyone who simply never wants to close a browser tab again.
TIP FOR YOU
Dual-Channel for the Win 🚀
For the best performance, always try to install RAM in pairs of identical sticks (e.g., 2x 8GB instead of 1x 16GB). This allows the system to run in dual-channel mode, effectively doubling the data transfer bandwidth between the memory and the CPU. It's a "free" performance boost that makes a noticeable difference.
Your Step-by-Step Mini PC RAM Upgrade Guide 🔧
Ready to get hands-on? This process is surprisingly simple. While the exact steps vary slightly between models, the core principles for performing a mini PC RAM upgrade are universal for most modern units, including these versatile all-in-one mini PCs.
- Prep Your Workspace: Power down the mini PC completely and unplug all cables. Move it to a clean, well-lit area. Grab a small Phillips-head screwdriver and an anti-static wrist strap if you have one.
- Open the Case: Flip the unit over. You'll typically find four screws, often at the corners under the rubber feet. Unscrew them and gently lift the bottom panel off.
- Locate the RAM: You'll see one or two small, angled slots holding the SODIMM sticks. They're secured by a metal clip on each side.
- Remove Old RAM (If Necessary): To remove an existing stick, gently push both metal clips outwards simultaneously. The stick will pop up at an angle. You can then slide it out of the slot.
- Install the New RAM: Take your new SODIMM stick, align the notch on the stick with the key in the slot, and insert it firmly at a 30-45 degree angle. Once it's fully seated, press it down towards the motherboard until the side clips click into place, securing it flat.
- Close Up & Test: Replace the bottom panel, screw it back on, and plug everything back in. Power on your mini PC.
MSI Cubi NUC AI+ 2MG-026ZA Mini Desktop / Intel Core Ultra 9 288V (8x Cores, 8x Threads, 3.30GHz Base) up to 5.10GHz / LPDDR5x 32GB RAM / 1TB NVMe SSD / Integrated Intel Arc Graphics / Windows 11 Pro / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A, 2x Thunderbolt 4, 1x Microphone & Headphone Combo Jack, 1x Micro-SD Card Reader, 1x Power Button with Fingerprint Security Design, 1x Copilot Button, 2x RJ45, 1x HDMI, 1x Kensington Lock, 1x External Power Switch Pin Header / 9S6-B20611-026
R23499.00In Stock
MSI Cubi NUC AI+ 2MG-041ZA Mini PC / Intel Core Ultra 5 226V (8x Cores, 8x Threads, 2.1GHz Base) up to 4.5GHz / 16GB LPDDR5x RAM / 512GB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Professional / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports Thunderbolt 4, DisplayPort) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-041
R17499.00In Stock
MSI Cubi NUC AI+ 2MG-027ZA Mini PC / Intel Core Ultra 7 258V (8x Cores, 8x Threads, 2.2GHz Base) up to 4.8GHz / 32GB LPDDR5x RAM / 1TB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Home / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports ) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-027
R19999.00In Stock
MINISFORUM AI X1-255 Mini PC with AMD Ryzen 7 255 (8C/16T, up to 5.1 GHz), 16GB DDR5 Memory, 512GB SSD Storage, HDMI/DP/USB4 (4K@120 Hz), Dual Speaker/DMIC,USB-A X 3, 2.5G LAN, Wi-Fi 7/BT5.4 / AI-X1-255
R9999.00In Stock
MSI Cubi NUC AI 1UMG Mini PC Intel Core Ultra 5(up to 4.5GHz) Desktop Computer, DDR5 16GB RAM 512GB SSD, 2x HDMI, 2x USB Type-A, 2x USB Type-C (Thunderbolt 4 / DisplayPort 1.4) , 1x 2.5G LAN Port / 9S6-B20911-059
R15199.00In Stock
MINISFORUM Mini PC NAB6 Lite Intel Core i5-12600H,12 Cores 16 Threads,up to 4.5GHz 32GB RAM DDR4 1TB PCIe4.0 SSD Dual 2.5 G RJ45 LAN Mini Desktop Computer,2 x HDMI,7 x USB Port,WiFi 6,BT5.2 / NAB6-Lite
R8999.00In Stock
After the Upgrade: Verifying Your Success
The first boot after installing new RAM might take a little longer than usual—don't panic! This is just your system recognising the new hardware.
Once you're booted into Windows, right-click the Start button, go to System, and check the "Installed RAM" value. It should now reflect your new total. You'll immediately feel the difference in how snappy and responsive your machine is. Brands like Minisforum design their chassis for easy access, making this entire process a breeze.
You've just completed one of the easiest and most impactful DIY tech upgrades possible. Enjoy the extra breathing room!
Ready to Supercharge Your Setup? A Mini PC offers incredible power in a tiny footprint. Whether you're upgrading your current rig or looking for a brand new compact beast, Evetech has you covered. Explore our massive range of Mini PCs and find the perfect machine to conquer your world.
Related Products
MSI Cubi NUC AI+ 2MG-027ZA Mini PC / Intel Core Ultra 7 258V (8x Cores, 8x Threads, 2.2GHz Base) up to 4.8GHz / 32GB LPDDR5x RAM / 1TB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Home / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports ) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-027
R19999.00In Stock
MSI Cubi NUC AI+ 2MG-026ZA Mini Desktop / Intel Core Ultra 9 288V (8x Cores, 8x Threads, 3.30GHz Base) up to 5.10GHz / LPDDR5x 32GB RAM / 1TB NVMe SSD / Integrated Intel Arc Graphics / Windows 11 Pro / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A, 2x Thunderbolt 4, 1x Microphone & Headphone Combo Jack, 1x Micro-SD Card Reader, 1x Power Button with Fingerprint Security Design, 1x Copilot Button, 2x RJ45, 1x HDMI, 1x Kensington Lock, 1x External Power Switch Pin Header / 9S6-B20611-026
R23499.00In Stock
MINISFORUM AI X1-255 Mini PC with AMD Ryzen 7 255 (8C/16T, up to 5.1 GHz), 16GB DDR5 Memory, 512GB SSD Storage, HDMI/DP/USB4 (4K@120 Hz), Dual Speaker/DMIC,USB-A X 3, 2.5G LAN, Wi-Fi 7/BT5.4 / AI-X1-255
R9999.00In Stock
MSI Cubi NUC AI+ 2MG-041ZA Mini PC / Intel Core Ultra 5 226V (8x Cores, 8x Threads, 2.1GHz Base) up to 4.5GHz / 16GB LPDDR5x RAM / 512GB NVMe SSD / Intel Arc Integrated Graphics / Windows 11 Professional / Intel Wi-Fi 6E AX211 / Bluetooth 5.3 / 4x USB Type-A / 2x USB Type-C (Supports Thunderbolt 4, DisplayPort) / 2x RJ45 / 1x HDMI / 1x Microphone & Headphone Combo Jack / 1x Micro SD Card Reader / Fingerprint Reader / Copilot / External Power Button / 9S6-B20611-041
R17499.00In Stock
MSI Cubi NUC AI 1UMG Mini PC Intel Core Ultra 5(up to 4.5GHz) Desktop Computer, DDR5 16GB RAM 512GB SSD, 2x HDMI, 2x USB Type-A, 2x USB Type-C (Thunderbolt 4 / DisplayPort 1.4) , 1x 2.5G LAN Port / 9S6-B20911-059
R15199.00In Stock
MINISFORUM Mini PC NAB6 Lite Intel Core i5-12600H,12 Cores 16 Threads,up to 4.5GHz 32GB RAM DDR4 1TB PCIe4.0 SSD Dual 2.5 G RJ45 LAN Mini Desktop Computer,2 x HDMI,7 x USB Port,WiFi 6,BT5.2 / NAB6-Lite
R8999.00In Stock
Absolutely. Upgrading RAM is one of the most cost-effective ways to boost your mini PC's performance, improving multitasking, speeding up applications, and enhancing overall responsiveness.
This depends on your specific model's motherboard and processor. Most modern mini PCs support between 16GB and 64GB of RAM. Always check your device's manual for its maximum capacity.
The vast majority of mini PCs use SODIMM (Small Outline Dual In-line Memory Module) RAM, which is the compact form factor used in laptops. Always verify the correct type (e.g., DDR4, DDR5).
While many mini PCs are designed for easy upgrades, some budget or ultra-slim models have their RAM soldered to the motherboard. It is crucial to check if your model has accessible RAM slots.
To ensure you buy the right memory, check your mini PC's specifications for the required RAM type (DDR4/DDR5), speed (MHz), and maximum supported capacity. Mismatched RAM may not work.
The key benefits of a RAM upgrade include faster application loading, smoother multitasking with many open tabs or programs, and improved performance in memory-intensive tasks.
